Pattern Design-Architectural

19 classic colors
Dimension
2.0mm×2m×20m
Wearlayer Thickness
0.6mm
  • Pattern Design-Architectural
  • Pattern Design-Architectural
  • Pattern Design-Architectural
  • Pattern Design-Architectural
  • Pattern Design-Architectural

Description

Homogeneous vinyl is made of one single layer that offers a wide choice of natural colors. It is incredibly durable and stain resistant which makes it a great flooring choice for hospital, school, laboratory, office, etc

Structure

①PUR Coating  ②PVC Wear Layer  ③Printed Layer  ④Dimensional Layer  ⑤Compact Layer

Features

· Wear Resistance

With a high-thickness wear-resistant layer and special PUR treatment, it is more wear-resistant

· Stain-Resistant And Easy To Clean

Special PUR surface treatment, no need for spraying, keeping as clean and shiny as new

· Comfortable Foot Feel

It adopts a highly elastic and dense structure, with pressure buffering and gradual rebound

· Antibacterial And Antifungal

Utilizing silver nanotechnology for antibacterial treatment

· Dimensional Stability

Advanced proportional fiber layers are adopted

· Anti-aging And Non-Fading

Utilizing BASF stabilizer from Germany to maintain bright colors

Color


DESCRIPTION STANDARD RESULT
Surface Treatment _ PUR
Total thickness ISO 24346-EN 428 2.0mm
Wear layer thickness ISO 24346-EN 429 0.4/0.6mm
Weight ISO 24346-EN 430 3000g/m²
Width of sheet ISO 24346-EN 426 2m
Length of sheet ISO 24346-EN 426 20m
Abrasion group EN 660 T
Dimensional stability EN 434 ≤0.4%
Residual indentation EN 433 ≤0.1mm
Castor chair test EN 425 OK
Colour fastess to light ISO 105-B02 ≥6
Slip resistance DIN 51130 R9
Impact sound resisitance EN ISO71712 19dB
Staining resistance ENISO 26987 OK
Reaction to fire EN ISO 13501-1 classBf1-s1
Toxic testing GB/18586-2001 Qualified


Scan the code to view the installation tutorial
